Specifications
| GENERAL | |
| Supply voltage | 24 VDC |
| Power consumption at 24V DC | <40mA |
| Pressure rating | 0…20 bar (0…290 psi) |
| Measurement range | 0 -100% RH |
| Housing / protection rating | Stainless steel 1.4404 / IP65 |
| Connection | G1/2’’ BSP |
| Electrical connection¹ | M12 8-pin plug |
| Sensor protection | Stainless steel filter |
| Oil temperature | -40…100 °C (-40…212 °F) |
| Ambient temperature | -40…80 °C (-40…176 °F) |
| Storage temperature | -40…60 °C (-40…140 °F) |
| Electromagnetic compatibility | EN61326-1 EN61326-2-3 |
| Fluid compatibility² | Petroleum based and synthetic fluids |
| OUTPUT | |
| 2 x analogue output | 4 – 20 mA (3-wire technology) <500 Ohm |
| Digital output | MODBUS RTU |
| ACCURACY AT 20°C³ | |
| Humidity Sensor | ± 2% 0 to 90% & ±3% 90 to 100% |
| Temperature in oil | ±0.2 °C (0.36 °F) |
| Response time | < 10 min. in still oil |
¹M12 8-pins connector is included. Contact RMF Systems for connection diagram
²The MCS is not suitable for water based fluids or aerospace phosphate ester hydraulic fluids.
³The accuracy statement includes the uncertainty of the factory calibration with an enhancement factor k=2 (2 x standard
deviation). The accuracy was calculated in accordance with EA-4/02 and with regard to GUM (Guide to the Expression of
Uncertainty in Measurement).
Did You Know...
Contamination is the greatest single cause of lubrication malfunction and subsequent excessive wear of parts?
Less than 0.5% of a plant’s maintenance budget is spent purchasing lubricants, but the downstream effects of poor lubrication can impact as much as 30% of a plant’s total maintenance cost each year.
It cost ten times as much to remove contamination from equipment than it does to exclude it?
