Specifications
GENERAL
- Ordering Code: OQS2-01-A-V
PHYSICAL
- Material: Stainless Steel: AISI304
- Weight: 0.4 lb (180 g)
- Connection: 32mm AF Hex Collar
- Torque: 25Nm
- Connection Thread: 1/2’’ BSPP male
CONNECTIONS
- Connector: 6 pin Bulgin 4000 series
ELECTRICAL
- Power Supply: 9-30 V DC
- Consumption: 0.4W Average
DATA OUTPUT
- Digital Output: RS485, CANbus
- Protocols Supported: Modbus, CanOpen and J1939
- Analog Output: 4-20mA
OIL QUALITY DETECTION PARAMETERS
- Frequency: Every 2 seconds
- Output: Oil Condition, Oil Temperature (°F or °C)
- Sensitivity / Accuracy: 0.01%, +/-0.5%
- Elements: All wear and contamination
OIL TYPE
- Configuration: Any mineral, semi-synthetic or synthetic oil, including fuels (diesel & bio-diesel)
ENVIRONMENTAL
- Fluid Pressure: up to 70 bar (1015 psi)
- Operating Temperature: -40°F to 248°F (-40°C to +120°C)
- Calibrated Temperature: -4°F to 248°F (-20°C to +120°C)
- Fluid Temperature: -40°F to 248°F (-40°C to +120°C)
- Storage Temperature: -67°F to 302°F (-55°C to +150°C)
STANDARDS & CERTIFICATIONS
- Water & Dust: IP68 when connected
- Shock & Vibration: BS EN 60068-2-30 (Test Db – Cyc.Hum.)
BS EN 60068-2-6 (Test Fc – Sine Vib.)
BS EN 60068-2-27 (Test Ea – Mech.Shock) - EMC: EN 61000-6-4:2007 (Generic Emissions Standard for Industrial Environments)
EN 61000-6-2:2005 (Generic Immunity Standard for Industrial Environments) - Conformity: CE Marked, RoHS Compliant
Features
The sensor is a live, highly flexible and cost effective condition based monitoring solution, designed to be permanently mounted within any lubrication system on any type of machine. Over 60 times more sensitive to oil contamination than any other dielectric constant measuring sensor, it provides real-time monitoring of oil condition, water ingress and oxidation levels.
- Reduced maintenance costs
- Extended oil change intervals
- Scheduled downtime intervals for increased productivity
- Reduced waste oil cost
- Improved equipment reliability
- Low cost investment tool
- Reduced carbon foot print
- Reduces total cost of ownership
Oil Quality Display (OQD)
The Oil Quality Display is a simple but powerful device which allows you to read the quality and temperature of the oil from a Oil Quality Sensor without a PC. This enables you to set up the display box on site and then be able to see the oil quality and temperature readings as required. Use an Android app to connect your Smartphone with the OQD smart via Bluetooth. Due to a polycarbonate housing and a IP67 rating (when connected), this product can be placed in all industrial environments without any doubts of damaging it or installing the OQD in a dry place. The new ‘Rate of Change’ feature allows you to easily monitor the degradation of oil over a programmable period of time.
Did You Know...
The value of adding digitalization increases productivity between 3-5%?
There will be 7.5 Billion connected devices by 2020.
As sensors spread across almost every industry, the internet of things is going to trigger a massive influx of big data?
